Operation Manual / A150-M56/66/57/67 - A155-M..
18 Spare parts / 18.3 Spare part – Illustrations
© Copyright 2021 ABB. All rights reserved.
HZTL4032_EN
Rev.Q
January 2021
Part no.
Designation
42194
Gasket
42195*
O-ring
42196
Orifice oil inlet
42197
Safety-ring
42200*
O-ring
42201
Clamping nut
42202
Screw plug
Table78: Spare parts - Cartridge, oil cooled
Page 175 / 194
176
178
