7.5 Changing the absorption element
The absorption element(81148) in uncoupled filter silencers must be replaced every 12000
hours of operation.
Disassembling the absorption element
Fig.37: Disassembling the absorption element
1. Remove the filter silencer (see Fig.49: Removing the uncoupled filter silencer →100).
2. Dismantle the hexagon-head screws(81152) with washers(81153) and mounting
plate(81149).
3. Remove the socket screws(81154), roll pins(81151), flanges(81145 / 81146) and absorp-
tion element(81148).
