Operation Manual / A150-M56/66/57/67 - A155-M..
7 Periodic maintenance work / 7.4 Cleaning components mechanically
© Copyright 2022 ABB. All rights reserved. HZTL4032_EN Rev.S February 2022
(see Fig.32: Cleaning the filter silencer →70)
Dismantling and cleaning the cover grid(81266)
u Loosen and remove lock nuts (81273).
u Loosen and remove screws (81272) to the connecting rods (81269).
Have damaged connecting rods replaced by a Turbo Systems service station.
u Remove connecting rods (81269).
u Remove and clean cover grid (81266).
Cleaning the absorption segments(81136)
u Pull out and bend up the sheet-metal coverings(81137), and remove the absorption seg-
ments(81136).
u Clean the absorption segments.
When cleaning, note that the absorption segments may only be cleaned lightly with pres-
surized air, a soft brush or a moist cleaning cloth.
u Have any heavily contaminated absorption segment replaced by a Turbo Systems service
station.
Fitting the filter silencer
u Insert the absorption segments(81136) into the sheet-metal coverings(81137).
u Bend the sheet-metal coverings(81137) back to their original shape and insert into the
slotted guides in the filter silencer body(81135).
u If the cleaning container is present on the filter silencer: Reinstall the water injection pipe.
Page 71 / 198
