Manual Power Quality Filter PQFM The PQF-Manager user interface 103
Table 43: Summary of parameters displayed in the ‘Overview’ menu
wire mode: RMS value of all the line
3-wire mode: RMS value of all the line-to-line voltages
wire mode: Total harmonic distortion of all the line
voltages
3-wire mode: Total harmonic distortion of all the line-to-line
voltages
the fundamental component of all the
line-to-neutral voltages
3-wire mode: RMS value of the fundamental component of all the
line-to-line voltages
Active filter DC capacitor voltage
alance in supply voltage (%value)
wire mode: RMS value of all the line currents and the neutral
current
3-wire mode: RMS value of all the line currents
Total harmonic distortion of all the line currents.
RMS value of the fundamental
component of all the line currents
RMS value of all the filter currents, including neutral current for 4
wire configuration
kW,
MW
Active power in the network at the location of the CTs
P > 0: Load absorbing active power
P < 0: Load generating active power
kvar
Mvar
Reactive power in the network at the location of the CTs
Q > 0: Inductive reactive power
Q < 0: Capacitive reactive power
kVA,
MVA
Apparent power in the network at the location of the CTs
lculation based on the fundamental and the
harmonic values of the measurements. Measurement only valid
for quasi-balanced loads.
Displacement power factor: calculation based on the
fundamental values of the measurements.
: System has inductive behavior
: System has capacitive behavior
cos ϕ > 0: load absorbing active power
cos ϕ < 0: load generating active power
Main control board temperature of the selected module
Main control board temperature of the
group
