Manual Power Quality Filter PQFM  Technical specifications 223
—
12 Technical specifications
12.1 What this chapter contains
This chapter contains the technical specifications of the active filter PQFM.
12.2 Technical specifications
The PQFM is an active filter for three phase networks with or without neutral for filtering
of non-zero sequence harmonics and reactive power compensation including balancing
between phases.
Table 67: Technical Specifications
Installation location
Indoor installation on firm foundation in a clean environment
Altitude
Nominal output at 0 to 1000m (3300ft) above sea level (for
derating refer to Table 13)
Minimum temperature
-
10°C (23°F) non condensing
Maximum temperature
40°C (104°F) (for derating refer to Table 13)
Recommended maximum average
temperature (over 24 h)
35
°C (95°F)
Relative humidity
Max. 95%
non
-
condensing
during operation.
Max. 85% non-condensing during storage.
Contamination levels (IEC 60721
-
3
-
3)
Chemical class 3C2 (for more information refer to Table
13)
Mechanical class 3S2 (for more information refer to Table
13)
Vibration (IEC 60068
-
2
-
6)
Max. 0.3mm (2
-
9Hz)
Max. 1m/s
2
(9-200Hz)
Shock (IEC 60068
-
2
-
27)
Max. 40m/s²
-
22ms
Filter in
stallation information
Standard degree of protection
Cubicle version: IP21 (IP20 open door)
Plate version: IP00
For other protection classes see options.
Dimensions per power unit (appr.)
W x D x H: 6
00 x 600 x 2150 mm (without base frame)
Plate: W x D x H: 498 x 432 x 1697 mm
Note: Tolerance between 0 and 6 mm is applicable
Approximate w
eight per power unit cubicle (unpacked)
Network voltage: 208 V
≤
Ue
≤
480 V
(Voltage group V1)
Unit rating: 70 A
IP21: 2
6
0 kg
IP00: 180 kg
Network voltage: 208 V
≤
U
e
≤
480 V
IP21: 260 kg
