94 The PQF-Manager user interface Manual Power Quality Filter PQFS
T limit reached
The filter temperature limit has been reached and the filter
is derating itself to run at a safe temperature
In standby The filter is in standby
Activ. Main The main active filter settings are activated
Activ. Aux The auxiliary active filter settings are activated
Unit miss.
One of the filter units in a multi-unit arrangement is not
available (e.g. due to a permanent error), or has not yet
been commissioned.
Pg. alarm 1 The programmable alarm 1 is activated
Pg. alarm 2 The programmable alarm 2 is activated
Pg. alarm 3 The programmable alarm 3 is activated
Warning 1 The programmable warning 1 is activated(c)
Warning 2 The programmable warning 2 is activated(c)
Warning 3 The programmable warning 3 is activated(c)
Following are the default functions set for the six digital output contacts:
Table 40 Main screen
