80
FEM630 | ELECTROMAGNETIC FLOWMETER | OI/FEM630-EN REV. A
Menu / parameter
Device Info / ...Transmitter
Transmitter Type
Transmitter ID ID number of transmitter.
Transm.Serial No. Serial number of transmitter.
...Transmitter Version
Selection of submenu ‘...Transmitter Version’ using .
Transm. Run Hours Run hours of the transmitter.
Tx Restart Counter Number of device restarts (cyclically switching the power supply off and on).
Time since Restart Device operating hours since the last restart.
If the plug-in card is incorrectly detected or incompatible, a corresponding message will be issued.
...Tx Calibration
Selection of submenu ‘...Tx Calibration’ using .
Manufacturer Name of manufacturer.
Street Manufacturer's address (street).
City Manufacturer's address (city).
Phone Manufacturer's address (phone number).
Device Info / ...Transmitter / ...Transmitter Version
FW Device Ver.
Version and item number of device software package.
FW Device Part Nr.
FW Motherboard Ver.
Version and checksum (CRC) of motherboard (MB) software.
FW Motherboard CRC
FW Frontend Ver.
Version and checksum (CRC) of the frontend board (FEB) software.
FW Frontend CRC
HW Motherboard Ver. Hardware version of the motherboard (MB).
HW Frontend Ver. Hardware version of the frontend board (FEB).
Bootloader MB Ver. Version of motherboard (MB) bootloader.
Bootloader FEB Ver. Version of frontend board (FEB) bootloader.
Curr. Out FW Ver.
Current output module software version and checksum (CRC).
Curr. Out FW CRC
Software version and checksum (CRC) of the optional plug-in card
Device Info / ...Transmitter / ...Tx Calibration
Calibration value of the transmitter.
First Cal. Date Date of first calibration of transmitter (calibration of new device).
Last Cal. Date Date of last calibration of transmitter.
Cal. Cert. No. Identification (number) of the relevant calibration certificate.
First Cal. Location Place of first calibration of transmitter.
Last Cal. Location Place of last calibration of transmitter.
8 ...Operation
...Parameter descriptions
