ABB ProcessMaster FEM631 - Selecting and Changing Parameter; Entry from Table

65
FEM630 | ELECTROMAGNETIC FLOWMETER | OI/FEM630-EN REV. A
Alphanumeric entry
When an alphanumeric entry is made, a value is set by
entering the individual decimal positions.
1 Select the parameters you want to set in the menu.
2 Use to call up the parameter for editing. The decimal
place that is currently selected is highlighted.
3 Use to select the decimal place to change.
4 Use / to set the desired value.
5 Use to select the next decimal place.
6 If necessary select and set additional decimal places in
accordance with steps 3 to 4.
7 Use to confirm your setting.
This concludes the procedure for changing a parameter value.
Numerical entry
When a numerical entry is made, a value is set by entering the
individual decimal positions.
1 Select the parameters you want to set in the menu.
2 Use to call up the parameter for editing. The decimal
place that is currently selected is highlighted.
8 ...Operation
Selecting and changing parameter
Parameter name
12.3456 [unit]
Next 
Parameter name
ABC………

Next 
Menu name
Parameter name
Currently set value
Next Edit
Entry from table
When an entry is made from a table, a value is selected from a
list of parameter values.
1 Select the parameters you want to set in the menu.
2 Use to call up the list of available parameter values.
The parameter value that is currently set is highlighted.
3 Select the desired value using / .
4 Confirm the selection with .
This concludes the procedure for selecting a parameter value.
Menu name
Parameter name
12.3456 [unit]
Next Edit
Parameter name
Parameter 1
Parameter 2
Parameter 3
Cancel 
Menu Name
Parameter name
Currently set value
Next Edit
3 Use to select the decimal place to change.
4 Use / to set the desired value.
5 Use to select the next decimal place.
6 If necessary select and set additional decimal places in
accordance with steps 3 to 4.
7 Use to confirm your setting.
This concludes the procedure for changing a parameter value.
