FEP630, FEH630 ELECTROMAGNETIC FLOWMETER | OI/FEP630/FEH630-EN REV. D 101
Menu / parameter Description
Diagnostics / ...Diagnosis Control / ...Noise Check
Start Noise Check Start the ‘Noise Check’ function, using .
Result Noise Check The LCD display displays the results of the Noise Check.
Power Spectrum Current power spectrum.
Amplitude 1 Value Display the four highest amplitudes in the power spectrum.
Amplitude 2 Value
Amplitude 3 Value
Amplitude 4 Value
Frequency 1 Display the four highest amplitudes in the frequency corresponding to the power spectrum.
Frequency 2
Frequency 3
Frequency 4
Diagnostics / ...Diagnosis Control / ...Fingerprints
Tx Factory CMR The ‘fingerprint database’ allows for a comparison of the values at the time of factory calibration with the currently
recorded values. Errors in the integrity of the device can already be detected early on. Corrective measures can be taken.
Here: Display of the determined values at the time of the factory calibration.
Tx Factory 1m/s
Tx Factory 10m/s
Se Factory Coil Ind.
Se Factory Imp. E1
Se Factory Imp.E2
Start. FP verification Create a fingerprint and perform verification.
Result FP verification Display of the verification result. Based on the result, one of the following messages will be issued.
‘FP Verificat. passed’, ‘CMR failed’, ‘1m/s failed’, ‘CMR, 1m/s failed‘10m/s failed’, ‘CMR, 10m/s failed‘1m/s, 10m/s failed', ‘All
TxFingerp.failed‘Coil Fingerp. Failed’, ‘CMR, Coil failed‘1m/s, Coil failed’, ‘CMR,1m/s,Coil failed‘10m/s, Coil failed’,
‘CMR,10m/s,Coil faile‘1, 10m/s,Coil failed’, ‘All Fingerp. failed‘No Verific.performed’
Tx Customer CMR The manual fingerprint is created on-site prior to verification of the transmitter.
Here: Display of the determined values.
Tx Customer 1m/s
Tx Customer 10m/s
Se Customer Coil Ind
Se Customer Imp. E1
Se Customer Imp. E2
To Next Page
