90 FEP630, FEH630 ELECTROMAGNETIC FLOWMETER | OI/FEP630/FEH630-EN REV. D
… 8 Operation
… Parameter descriptions
Menu / parameter Description
Input/Output / ...Dig.Out 41/42 / ...Setup Pulse Output
Output Value Pulse Selection of process variable that is issued via the pulse output.
• Off: The pulse output is deactivated.
• Pulse Mass Flow: The pulse output indicates the mass flow.
• Pulse Volume Flow: The pulse output indicates the volume flow.
Pulses per Unit Sets the pulses per mass unit or volume unit (see table Available units on page 78) and the pulse width for the pulse output.
The potential pulse width depends on the configured pulse value and is calculated dynamically.
Pulse Width
Input/Output / ...Dig.Out 41/42 / ...Setup Freq Output
Output Value Freq. Selection of process variable that is issued via the frequency output.
• Off: The pulse output is deactivated.
• Pulse Mass Flow: The pulse output indicates the mass flow.
• Pulse Volume Flow: The pulse output indicates the volume flow.
Upper Frequency Sets the frequency for the upper range value. The entered value corresponds to 100 % flow.
Input/Output / ...Dig.Out 41/42 / ...Setup Logic Output
Logic Output Action Selection of binary output function.
• Off: The binary output is deactivated.
• F/R Signal: The binary output signals the flow direction.
• Alarm Signal: The binary output indicates an active alarm. The alarm is selected in the ‘„...Alarm Config’ menu.
• Dual Range: The binary output is activated when measuring range 2 (Qm Max 2 / Qv Max 2) is selected. This selection is
only available if the parameter ‘Dual Range’ has been configured to Qm or Qv.
• Batch End Contact: The binary output is activated when the set fill quantity is reached (only if the FillMass function is
activated).
Active Mode Select switching properties for the binary output.
• Active High: Normally open
• Active Low: Normally closed
Default setting: Active High.
