Apparatus control
ABB Network Partner AB
1MRK 580 150-XEN
Page 6 - 37
Version 1.0-00
4 are used only for event handling of the positions for one pole of the cir-
cuit breaker. For event handling of all three poles separately, an additional
Event Function block is needed.
Fig. 22 Event connections between the station MMI and apparatus
control modules for one apparatus
SWICON
CX
OX
MA_UPD_P
SEL_OPEN
SEL_CLOS
SEL_ERR
CMD_ERR
POS_ERR
POL_DISC
COMCON
OVERRIDE
LO_OP_T
BLKCONL
BLK_OUT1
≥1
Apparatus 1
Interlocking
ITL
&
INPUT1
INPUT2
INPUT3
INPUT4
INPUT5
INPUT6
INPUT7
INPUT8
INPUT9
INPUT10
INPUT11
INPUT12
INPUT13
INPUT14
INPUT15
INPUT16
EVENT
POS_CL
POS_OP



From
input
board
RES_ERR
Interlocked
To station MMI
Tripped
(X80150-22)
