ABB Network Partner AB
Apparatus control
Version 1.0-00
1MRK 580 150-XEN
Page 6 - 80
7.2.6 BAYCONF
Table 11: Input signals for BAYCONF
IN: DESCRIPTION:
BFxx-S_R Input to change operator place to Remote
(pulse input)
BFxx-S_S Input to change operator place to Station
(pulse input)
BFxx-L_L Input to change operator place to Local
BFxx-EXCH_IN Input for information exchange with other
BAYCON:s in bays with more than 8 appa-
ratuses
BFxx-RQ_SEL1 Request for selection and reservation of
apparatus 1
BFxx-RQ_SEL2 Request for selection and reservation of
apparatus 2
BFxx-RQ_SEL3 Request for selection and reservation of
apparatus 3
BFxx-RQ_SEL4 Request for selection and reservation of
apparatus 4
BFxx-RQ_SEL5 Request for selection and reservation of
apparatus 5
BFxx-RQ_SEL6 Request for selection and reservation of
apparatus 6
BFxx-RQ_SEL7 Request for selection and reservation of
apparatus 7
BFxx-RQ_SEL8 Request for selection and reservation of
apparatus 8
BFxx-BLK_RE Input for blocking all reservations
BFxx-OVERRIDE Input for overriding the reservation function
including the blocking by BLK_RE
BFxx-RE_B1 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 1
BFxx-RE_B2 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 2
BFxx-RE_B3 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 3
BFxx-RE_B4 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 4
BFxx-RE_B5 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 5
BFxx-RE_B6 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 6
BFxx-RE_B7 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 7
BFxx-RE_B8 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 8
