Apparatus control
ABB Network Partner AB
1MRK 580 150-XEN
Page 6 - 81
Version 1.0-00
BFxx-ACK_F_B Input for acknowledging the reservation of
other bays
BFxx-ANY_ACK Input indicating that at least one acknowl-
edge is still active
BFxx-V_TX Indication for valid transmission of the reser-
vation signals
BFxx-EX_DA_UP Input is 1 if the program that acknowledged
the reservation is running
BFxx-RE_RQ_B Request for reservation from other bays
BFxx-V_RE_RQ Input is 1 for valid request of reservation
from any bay
BFxx-SEL_ACT1 Selection of apparatus 1 is activated by the
program and the selection relay should be
energized
BFxx-SEL_ACT2 Selection of apparatus 2 is activated by the
program and the selection relay should be
energized
BFxx-SEL_ACT3 Selection of apparatus 3 is activated by the
program and the selection relay should be
energized
BFxx-SEL_ACT4 Selection of apparatus 4 is activated by the
program and the selection relay should be
energized
BFxx-SEL_ACT5 Selection of apparatus 5 is activated by the
program and the selection relay should be
energized
BFxx-SEL_ACT6 Selection of apparatus 6 is activated by the
program and the selection relay should be
energized
BFxx-SEL_ACT7 Selection of apparatus 7 is activated by the
program and the selection relay should be
energized
BFxx-SEL_ACT8 Selection of apparatus 8 is activated by the
program and the selection relay should be
energized
BFxx-SEL_CH1 Indication that no selection or execution
relay is energized
BFxx-SEL_CH2 Indication that at least one selection or exe-
cution relay is energized
BFxx-INPBOERR Input for binary input board error
BFxx-OUTBOERR Input for binary output board error
BFxx-SEL_FDB1 Input for individual selection relay energiz-
ing of apparatus 1
BFxx-SEL_FDB2 Input for individual selection relay energiz-
ing of apparatus 2
BFxx-SEL_FDB3 Input for individual selection relay energiz-
ing of apparatus 3
Table 11: Input signals for BAYCONF
IN: DESCRIPTION:
