Apparatus control
Version 1.0-00
1MRK 580 150-XEN
Page 6 - 82
BFxx-SEL_FDB4 Input for individual selection relay energiz-
ing of apparatus 4
BFxx-SEL_FDB5 Input for individual selection relay energiz-
ing of apparatus 5
BFxx-SEL_FDB6 Input for individual selection relay energiz-
ing of apparatus 6
BFxx-SEL_FDB7 Input for individual selection relay energiz-
ing of apparatus 7
BFxx-SEL_FDB8 Input for individual selection relay energiz-
ing of apparatus 8
Table 12: Output signals for BAYCONF
OUT: DESCRIPTION:
BFxx-REMOTE Indication of Remote operator place
BFxx-STATION Indication of Station operator place
BFxx-LOCAL Indication of Local operator place
BFxx-EXCH_OUT Output for information exchange with other
BAYCON:s in bays with more than 8 appa-
ratuses
BFxx-SEL1 Apparatus 1 is selected after reservation
acknowledgement from other bays
BFxx-SEL2 Apparatus 2 is selected after reservation
acknowledgement from other bays
BFxx-SEL3 Apparatus 3 is selected after reservation
acknowledgement from other bays
BFxx-SEL4 Apparatus 4 is selected after reservation
acknowledgement from other bays
BFxx-SEL5 Apparatus 5 is selected after reservation
acknowledgement from other bays
BFxx-SEL6 Apparatus 6 is selected after reservation
acknowledgement from other bays
BFxx-SEL7 Apparatus 7 is selected after reservation
acknowledgement from other bays
BFxx-SEL8 Apparatus 8 is selected after reservation
acknowledgement from other bays
BFxx-RE A reservation has been made in this bay
BFxx-RE_BAYS Request for reservation of other bays
BFxx-ACK_T_B Acknowledgement to other bays that this
bay is reserved
BFxx-FDB_SEL1 Correct selection relay is energized for
apparatus 1
Table 11: Input signals for BAYCONF
IN: DESCRIPTION:
