Function block name Edition 1 logical nodes Edition 2 logical nodes
TR1ATCC TR1ATCC TR1ATCC
TR8ATCC TR8ATCC TR8ATCC
TRPTTR TRPTTR TRPTTR
U2RWPTUV GEN2LLN0
PH1PTRC
U2RWPTUV
PH1PTRC
U2RWPTUV
UV2PTUV GEN2LLN0
PH1PTRC
UV2PTUV
PH1PTRC
UV2PTUV
VDCPTOV VDCPTOV VDCPTOV
VDSPVC VDRFUF VDSPVC
VMMXU VMMXU VMMXU
VMSQI VMSQI VMSQI
VNMMXU VNMMXU VNMMXU
VRPVOC VRLLN0
PH1PTRC
PH1PTUV
VRPVOC
PH1PTRC
PH1PTUV
VRPVOC
VSGAPC VSGGIO VSGAPC
WRNCALH WRNCALH WRNCALH
ZC1PPSCH ZPCPSCH ZPCPSCH
ZC1WPSCH ZPCWPSCH ZPCWPSCH
ZCLCPSCH ZCLCPLAL ZCLCPSCH
ZCPSCH ZCPSCH ZCPSCH
ZCRWPSCH ZCRWPSCH ZCRWPSCH
ZCVPSOF ZCVPSOF ZCVPSOF
ZGVPDIS ZGVLLN0
PH1PTRC
ZGVPDIS
ZGVPTUV
PH1PTRC
ZGVPDIS
ZGVPTUV
ZMCAPDIS ZMCAPDIS ZMCAPDIS
ZMCPDIS ZMCPDIS ZMCPDIS
ZMFCPDIS ZMFCLLN0
PSFPDIS
ZMFPDIS
ZMFPTRC
ZMMMXU
PSFPDIS
ZMFPDIS
ZMFPTRC
ZMMMXU
ZMFPDIS ZMFLLN0
PSFPDIS
ZMFPDIS
ZMFPTRC
ZMMMXU
PSFPDIS
PSFPDIS
ZMFPDIS
ZMFPTRC
ZMMMXU
ZMHPDIS ZMHPDIS ZMHPDIS
Table continues on next page
Section 1 1MRK 511 401-UUS A
Introduction
34 Bay control REC670 2.2 ANSI
Application manual
