Function block name
Edition 1 logical nodes
Edition 2 logical nodes
ZMMAPDIS
ZMMAPDIS
ZMMAPDIS
ZMMPDIS
ZMMPDIS
ZMMPDIS
ZMQAPDIS
ZMQAPDIS
ZMQAPDIS
ZMQPDIS
ZMQPDIS
ZMQPDIS
ZMRAPDIS
ZMRAPDIS
ZMRAPDIS
ZMRPDIS
ZMRPDIS
ZMRPDIS
ZMRPSB
ZMRPSB
ZMRPSB
ZSMGAPC
ZSMGAPC
ZSMGAPC
1MRK 511 401-UUS A
Section 1
Introduction
Bay control REC670 2.2 ANSI
35
Application manual
40
42
Table of Contents
Default Chapter
7
Table of Contents
7
Section 1 Introduction
27
This Manual
27
Intended Audience
27
Product Documentation
28
Product Documentation Set
28
Document Revision History
29
Related Documents
30
Document Symbols and Conventions
30
Symbols
30
Document Conventions
31
IEC 61850 Edition 1 / Edition 2 Mapping
32
Section 2 Application
43
General IED Application
43
Main Protection Functions
44
Back-Up Protection Functions
45
Control and Monitoring Functions
46
Communication
54
Basic IED Functions
57
Section 3 Configuration
59
Description of Configuration REC670
59
Introduction
59
Description of Configuration A30
59
Description of Configuration B30
61
Description of Configuration C30
63
Description of Configuration D30
65
Section 4 Analog Inputs
67
Introduction
67
Setting Guidelines
67
Setting of the Phase Reference Channel
67
Example
68
Setting of Current Channels
68
Example 1
69
Example 2
69
Example 3
70
For most Commonly Used CT Connections
73
Example on How to Connect a Wye Connected Three-Phase CT Set to the IED
74
Example How to Connect Delta Connected Three-Phase CT Set to the IED
79
Example How to Connect Single-Phase CT to the IED
82
Relationships between Setting Parameter Base Current, CT Rated Primary Current and Minimum Pickup of a Protection IED
84
Example
85
Examples on How to Connect a Three Phase-To-Ground Connected VT to the IED
86
Example on How to Connect a Phase-To-Phase Connected VT to the IED
88
Example on How to Connect an Open Delta VT to the IED for High Impedance Grounded or Ungrounded Networks
90
Example How to Connect the Open Delta VT to the IED for Low Impedance Grounded or Solidly Grounded Power Systems
93
Section 5 Local HMI
97
Display
98
Leds
101
Keypad
102
Local HMI Functionality
104
Parameter Management
105
Front Communication
106
C37.118 Phasor Measurement Data Streaming Protocol Configuration PMUCONF
107
Short Guidance for Use of TCP
108
Short Guidance for Use of UDP
109
Protocol Reporting Via IEEE 1344 and C37.118 PMUREPORT
111
Application
112
Operation Principle
114
Frequency Reporting
116
Reporting Filters
118
Scaling Factors for ANALOGREPORT Channels
119
PMU Report Function Blocks Connection Rules in PCM600 Application Configuration Tool (ACT)
121
Setting Guidelines
127
High Impedance Differential Protection, Single Phase HZPDIF (87)
133
The Basics of the High Impedance Principle
135
Connection Examples for High Impedance Differential Protection
141
Connections for 1Ph High Impedance Differential Protection HZPDIF (87)
142
Setting Guidelines
143
Configuration
144
Tertiary Reactor Protection
148
Alarm Level Operation
151
Instantaneous Phase Overcurrent Protection PHPIOC (50)
153
Setting Guidelines
154
Meshed Network Without Parallel Line
155
Meshed Network with Parallel Line
157
Directional Phase Overcurrent Protection, Four Steps OC4PTOC(51_67)
159
Setting Guidelines
160
Settings for each Step
162
Setting Example
166
Instantaneous Residual Overcurrent Protection EFPIOC (50N)
171
Identification
174
Application
175
Setting Guidelines
177
Nd Harmonic Restrain
179
Switch Onto Fault Logic
180
Settings for each Step (X = 1, 2, 3 and 4)
181
Line Application Example
184
Four Step Directional Negative Phase Sequence Overcurrent Protection NS4PTOC (46I2)
189
Identification
190
Setting Guidelines
192
Common Settings for All Steps
195
Sensitive Directional Residual Overcurrent and Power Protection SDEPSDE (67N)
196
Identification
197
Setting Guidelines
199
Thermal Overload Protection, One Time Constant Fahrenheit Celsius LFPTTR/LCPTTR (26)
208
Setting Guideline
209
Breaker Failure Protection CCRBRF(50BF)
212
Setting Guidelines
213
Stub Protection STBPTOC (50STB)
216
Setting Guidelines
217
Pole Discrepancy Protection CCPDSC(52PD)
218
Setting Guidelines
219
Directional Underpower Protection GUPPDUP (37)
220
Setting Guidelines
222
Directional Overpower Protection GOPPDOP (32)
226
Setting Guidelines
228
Broken Conductor Check BRCPTOC (46)
232
Application
233
Application
234
SCB Protection
236
Setting Guidelines
238
Restrike Detection
240
Voltage-Restrained Time Overcurrent Protection VRPVOC (51V)
241
Base Quantities
242
Undervoltage Seal-In
243
Voltage-Restrained Overcurrent Protection for Generator and Step-Up Transformer
245
Two Step Undervoltage Protection UV2PTUV (27)
247
Setting Guidelines
248
Backup Protection for Power System Faults
249
Two Step Overvoltage Protection OV2PTOV (59)
250
Identification
251
Setting Guidelines
252
Power Supply Quality
253
Two Step Residual Overvoltage Protection ROV2PTOV (59N)
255
Setting Guidelines
256
Power Supply Quality
257
Direct Grounded System
258
Voltage Differential Protection VDCPTOV (60)
260
Setting Guidelines
262
Loss of Voltage Check LOVPTUV (27)
264
Underfrequency Protection SAPTUF (81)
265
Setting Guidelines
266
Identification
267
Rate-Of-Change of Frequency Protection SAPFRC (81)
268
Setting Guidelines
269
Frequency Time Accumulation Protection Function FTAQFVR (81A)
270
Setting Guidelines
272
General Current and Voltage Protection CVGAPC
275
Current and Voltage Selection for CVGAPC Function
276
Base Quantities for CVGAPC Function
279
Inadvertent Generator Energization
280
Setting Guidelines
281
Negative Sequence Overcurrent Protection
283
Generator Stator Overload Protection in Accordance with IEC or ANSI Standards
286
Open Phase Protection for Transformer, Lines or Generators and Circuit Breaker Head Flashover Protection for Generators
288
Voltage Restrained Overcurrent Protection for Generator and Step-Up Transformer
289
Multipurpose Filter SMAIHPAC
293
Setting Guidelines
295
Current Circuit Supervision (87)
299
Setting Guidelines
300
Setting Guidelines
301
Setting of Common Parameters
302
Zero Sequence Based
303
Dead Line Detection
304
Fuse Failure Supervision VDSPVC (60)
305
Setting Guidelines
306
Synchronism Check, Energizing Check, and Synchronizing SESRSYN (25)
309
Synchronism Check
311
Energizing Check
313
Voltage Selection
314
External Fuse Failure
315
Application Examples
316
Single Circuit Breaker with Single Busbar
317
Single Circuit Breaker with Double Busbar, External Voltage Selection
318
Single Circuit Breaker with Double Busbar, Internal Voltage Selection
319
Double Circuit Breaker
320
Breaker-And-A-Half
321
Setting Guidelines
324
Smbrrec (79)
329
Application
330
Auto Reclosing Operation off and on
333
Initiate Auto Reclosing and Conditions for Start of a Reclosing Cycle
334
Control of the Auto Reclosing Dead Time for Shot 1
335
Maximum Number of Reclosing Shots
336
Armode = 1/2Ph , 1-Phase or 2-Phase Reclosing in the First Shot
337
External Selection of Auto Reclosing Mode
338
Auto Reclosing Reset Timer
339
Lock-Out Initiation
340
Evolving Fault
341
Automatic Continuation of the Auto Reclosing Sequence
342
Auto Recloser Settings
351
Apparatus Control APC
356
Bay Control QCBAY
362
Switch Controller SCSWI
363
Proxy for Signals from Switching Device Via GOOSE XLNPROXY
364
Reservation Function (QCRSV and RESIN)
367
Interaction between Modules
369
Setting Guidelines
373
Switch (SXCBR/SXSWI)
374
Proxy for Signals from Switching Device Via GOOSE XLNPROXY
375
Bay Reserve (QCRSV)
376
Configuration Guidelines
377
Interlocking for Line Bay ABC_LINE (3)
378
Signals from Bus-Coupler
379
Configuration Setting
383
Interlocking for Bus-Coupler Bay ABC_BC (3)
384
Signals from Bus-Coupler
387
Configuration Setting
388
Interlocking for Transformer Bay AB_TRAFO (3)
389
Signals from Bus-Coupler
390
Configuration Setting
391
Interlocking for Bus-Section Breaker A1A2_BS (3)
392
Configuration Setting
395
Interlocking for Bus-Section Disconnector A1A2_DC (3)
396
Signals in Double-Breaker Arrangement
399
Signals in Breaker and a Half Arrangement
402
Interlocking for Busbar Grounding Switch BB_ES (3)
403
Signals in Single Breaker Arrangement
404
Signals in Double-Breaker Arrangement
408
Signals in Breaker and a Half Arrangement
409
Interlocking for Double CB Bay DB (3)
410
Interlocking for Breaker-And-A-Half Diameter BH (3)
411
Configuration Setting
412
Voltage Control
413
Setting Guidelines
449
TR1ATCC (90) or TR8ATCC (90) Setting Group
450
TCMYLTC and TCLYLTC (84) General Settings
460
Logic Rotating Switch for Function Selection and LHMI Presentation SLGAPC
461
Selector Mini Switch VSGAPC
462
Setting Guidelines
463
Setting Guidelines
464
Identification
465
Identification
466
Application
467
Setting Guidelines
468
Protection ZCPSCH(85)
471
Blocking Schemes
472
Delta Blocking Scheme
473
Permissive Schemes
474
Intertrip Scheme
478
Delta Blocking Scheme
479
Intertrip Scheme
480
Weak-End Infeed Logic
481
Setting Guidelines
482
Weak-End Infeed Logic
483
Setting Guidelines
484
Scheme Communication Logic for Residual Overcurrent Protection ECPSCH (85)
485
Setting Guidelines
486
Current Reversal and Weak-End Infeed Logic for Residual Overcurrent Protection ECRWPSCH (85)
487
Weak-End Infeed Logic
488
Current Reversal
489
Weak-End Infeed
490
Tripping Logic SMPPTRC (94)
491
Three-Pole Tripping
492
Single- And/Or Three-Pole Tripping
493
Single-, Two- or Three-Pole Tripping
494
Lock-Out
495
Blocking of the Function Block
497
Identification
498
Application
499
Application
500
Configuration
501
Fixed Signal Function Block FXDSIGN
502
Boolean 16 to Integer Conversion B16I
503
Application
504
Boolean to Integer Conversion with Logical Node Representation
505
Integer to Boolean 16 Conversion IB16
506
Integer to Boolean 16 Conversion with Logic Node Representation ITBGAPC
507
Identification
508
Elapsed Time Integrator with Limit Transgression and Overflow Supervision TEIGAPC
509
Comparator for Integer Inputs - INTCOMP
510
Setting Example
511
Comparator for Real Inputs - REALCOMP
512
Setting Example
513
Measurement
515
Application
516
Zero Clamping
517
Setting Guidelines
518
Setting Examples
521
Gas Medium Supervision SSIMG (63)
528
Setting Guidelines
529
Liquid Medium Supervision SSIML (71)
530
Breaker Monitoring SSCBR
531
Setting Guidelines
535
Event Function EVENT
536
Setting Guidelines
537
Identification
538
Setting Guidelines
539
Recording Times
542
Analog Input Signals
543
Sub-Function Parameters
544
Logical Signal Status Report BINSTATREP
545
Application
546
Setting Guidelines
547
Connection of Analog Currents
548
Limit Counter L4UFCNT
549
Application
550
Setting Guidelines
551
Setting Guidelines
556
Setting Example
565
Setting Parameters for Insulation Loss of Life Calculation Function (LOL1)
566
Pulse-Counter Logic PCFCNT
571
Function for Energy Calculation and Demand Handling ETPMMTR
572
Setting Guidelines
573
Access Point
575
Redundant Communication
577
Setting Guidelines
579
Merging Unit
580
Setting Guidelines
581
Communication Protocols
583
Sending Data
585
Receiving Data
586
LON Communication Protocol
588
MULTICMDRCV and MULTICMDSND
590
Setting Guidelines
592
IEC 60870-5-103 Communication Protocol
593
Design
594
Settings
596
Settings from PCM600
597
Function and Information Types
599
DNP3 Communication Protocol
600
Binary Signal Transfer
601
Communication Hardware Solutions
602
Setting Guidelines
603
Authority Status ATHSTAT
609
Change Lock CHNGLCK
610
Denial of Service SCHLCCH/RCHLCCH
611
Setting Guidelines
612
IED Identifiers TERMINALID
613
Factory Defined Settings
614
Identification
615
Setting Guidelines
616
Summation Block 3 Phase 3PHSUM
617
Application
618
Signal Matrix for Binary Outputs SMBO
619
Application
620
Setting Guidelines
621
Test Mode Functionality TESTMODE
626
Setting Guidelines
627
Time Synchronization TIMESYNCHGEN
628
Setting Guidelines
629
Current Transformer Requirements
633
Conditions
635
Fault Current
636
General Current Transformer Requirements
637
Breaker Failure Protection
638
Non-Directional Inverse Time Delayed Phase and Residual Overcurrent Protection
639
Directional Phase and Residual Overcurrent Protection
640
Current Transformer Requirements for Cts According to Other Standards
641
Current Transformers According to ANSI/IEEE
642
Voltage Transformer Requirements
643
Protection and Control Terminals in Digital Telecommunication Networks
644
Section 25 Glossary
647
Other manuals for ABB rec670
Operator's Manual
116 pages
Product Guide
138 pages
Commissioning Manual
218 pages
4
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the ABB rec670 and is the answer not in the manual?
Ask a question
ABB rec670 Specifications
General
Brand
ABB
Model
rec670
Category
Control Unit
Language
English
Related product manuals
ABB Relion REC670
482 pages
ABB REC650
656 pages
ABB REF542plus
104 pages
ABB REF 542plus
134 pages
ABB RELION Series
804 pages
ABB RPBA-01
113 pages
ABB RDCO-01
2 pages
ABB RTU500 series
90 pages
ABB REC670 2.1 IEC
116 pages
ABB Relion 670 series REC670
84 pages
ABB ACS850 series
28 pages
ABB Ability 800xA Series
124 pages
To Next PageTo Next PageTo Previous PageTo Previous Page
Loading...
Need help?
General
