ABB rec670 Applications Manual

IEC 61850 or
function name
ANSI Function description Bay control
REC670
(Customized)
LOCREMCTRL LHMI control of PSTO 1
SXCBR Circuit breaker 18
TR1ATCC 90 Automatic voltage control for tap changer, single control 0-4
TR8ATCC 90 Automatic voltage control for tap changer, parallel control 0-4
TCMYLTC 84 Tap changer control and supervision, 6 binary inputs 0-4
TCLYLTC 84 Tap changer control and supervision, 32 binary inputs 0-4
SLGAPC Logic rotating switch for function selection and LHMI
presentation
15
VSGAPC Selector mini switch 30
DPGAPC Generic communication function for Double Point
indication
16
SPC8GAPC Single point generic control function 8 signals 5
AUTOBITS Automation bits, command function for DNP3.0 3
SINGLECMD Single command, 16 signals 4
I103CMD Function commands for IEC 60870-5-103 1
I103GENCMD Function commands generic for IEC 60870-5-103 50
I103POSCMD IED commands with position and select for IEC
60870-5-103
50
I103POSCMDV IED direct commands with position for IEC 60870-5-103 50
I103IEDCMD IED commands for IEC 60870-5-103 1
I103USRCMD Function commands user defined for IEC 60870-5-103 4
Secondary system
supervision
CCSSPVC 87 Current circuit supervision 0-6
FUFSPVC Fuse failure supervision 0-4
VDSPVC 60 Fuse failure supervision based on voltage difference 0-2
Logic
SMPPTRC 94 Tripping logic 12
SMAGAPC General start matrix block 12
TMAGAPC Trip matrix logic 12
ALMCALH Logic for group alarm 5
WRNCALH Logic for group warning 5
INDCALH Logic for group indication 5
Table continues on next page
1MRK 511 401-UUS A Section 2
Application
Bay control REC670 2.2 ANSI 41
Application manual
