IEC 61850 or
function name
ANSI Function description Bay control
REC670
(Customized)
AND, GATE, INV,
LLD, OR,
PULSETIMER,
RSMEMORY,
SRMEMORY,
TIMERSET, XOR
Basic configurable logic blocks (see Table
3) 40-420
ANDQT,
INDCOMBSPQT,
INDEXTSPQT,
INVALIDQT,
INVERTERQT,
ORQT,
PULSETIMERQT,
RSMEMORYQT,
SRMEMORYQT,
TIMERSETQT,
XORQT
Configurable logic blocks Q/T (see Table 7) 0-1
AND, GATE, INV,
LLD, OR,
PULSETIMER,
RSMEMORY,
SLGAPC,
SRMEMORY,
TIMERSET,
VSGAPC, XOR
Extension logic package (see Table
8) 0-1
FXDSIGN Fixed signal function block 1
B16I Boolean to integer conversion, 16 bit 18
BTIGAPC Boolean to integer conversion with logical node
representation, 16 bit
16
IB16 Integer to Boolean 16 conversion 18
ITBGAPC Integer to Boolean 16 conversion with Logic Node
representation
16
TEIGAPC Elapsed time integrator with limit transgression and
overflow supervision
12
INTCOMP Comparator for integer inputs 30
REALCOMP Comparator for real inputs 30
Table 3: Total number of instances for basic configurable logic blocks
Basic configurable logic block Total number of instances
AND 280
GATE 40
INV 420
LLD 40
OR 298
Table continues on next page
Section 2 1MRK 511 401-UUS A
Application
42 Bay control REC670 2.2 ANSI
Application manual
