9.3.8 Technical data
Table 171: ROV2PTOV technical data
Function
Range or value Accuracy
Operate voltage,
step 1
(1-200)% of UBase ± 0.5% of U
r
at U < U
r
± 0.5% of U at U > U
r
Operate voltage,
step 2
(1–100)% of UBase ± 0.5% of U
r
at U < U
r
± 0.5% of U at U > U
r
Reset ratio > 98% -
Inverse time
characteristics for
low and high step,
see table
579
-
See table 579
Definite time setting,
step 1
(0.00–6000.00) s ± 0.5% ± 25 ms
Definite time setting,
step 2
(0.000–60.000) s ± 0.5% ± 25 ms
Minimum operate
time for step 1
inverse characteristic
(0.000-60.000) s
± 0.5% ± 25 ms
Operate time, start
function
30 ms typically at 0 to 2 x U
set
-
Reset time, start
function
40 ms typically at 2 to 0 x U
set
-
Critical impulse time 10 ms typically at 0 to 1.2 xU
set
-
Impulse margin time 15 ms typically -
9.4 Overexcitation protection OEXPVPH
9.4.1 Identification
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Overexcitation protection OEXPVPH
U/f >
SYMBOL-Q V1 EN
24
9.4.2 Functionality
When the laminated core of a power transformer or generator is subjected to a
magnetic flux density beyond its design limits, stray flux will flow into non-laminated
components that are not designed to carry flux. This will cause eddy currents to flow.
These eddy currents can cause excessive heating and severe damage to insulation and
