Table 339: IB16FCVB Output signals
Name Type Description
OUT1 BOOLEAN Output 1
OUT2 BOOLEAN Output 2
OUT3 BOOLEAN Output 3
OUT4 BOOLEAN Output 4
OUT5 BOOLEAN Output 5
OUT6 BOOLEAN Output 6
OUT7 BOOLEAN Output 7
OUT8 BOOLEAN Output 8
OUT9 BOOLEAN Output 9
OUT10 BOOLEAN Output 10
OUT11 BOOLEAN Output 11
OUT12 BOOLEAN Output 12
OUT13 BOOLEAN Output 13
OUT14 BOOLEAN Output 14
OUT15 BOOLEAN Output 15
OUT16 BOOLEAN Output 16
13.8.5 Settings
The function does not have any parameters available in local HMI or Protection and
Control IED Manager (PCM600)
13.8.6 Operation principle
An example is used to explain the principle of operation: With integer 15 sent to and
received by the IB16FCVB function on the IEC 61850 the OUTx changes from 0 to
1 on each of the OUT1; OUT2 OUT3 and OUT4. All other OUTx (5≤x≤16) remains
0. The boolean interpretation of this is represented by the assigned values of each of
the outputs OUT1 = 1; and OUT2 = 2; and OUT3= 4; and OUT4 = 8. The sum of these
OUTx (1≤x≤4) is equal to the integer 15 received via the IEC 61850 network. The
remaining OUTx = 0 for (5≤x≤16).
OUTx represents a value when activated. The value of each of the OUTx is in
accordance with the Table
340. When not activated the OUTx has the value 0.
The value of each OUTx for 1≤x≤16 (1≤x≤16) follows the general formulae: OUTx
= 2
x-1
The sum of the values of all activated OUTx = 2
x-1
where 1≤x≤16 will be equal
to the integer value received over IEC 61850 to the IB16FCVB_1 function block.
The Integer to Boolean 16 conversion with logic node representation function
(IB16FCVB) will transfer an integer with a value between 0 to 65535 communicated
via IEC 61850 and connected to the IB16FCVB function block to a combination of
Section 13 1MRK 502 048-UEN A
Logic
464
Technical manual
