SPVNZBAT activates the start and alarm outputs when the battery terminal voltage
exceeds the set upper limit or drops below the set lower limit. A time delay for the
overvoltage and undervoltage alarms can be set according to definite time
characteristics.
SPVNZBAT operates after a settable operate time and resets when the battery
undervoltage or overvoltage condition disappears after settable reset time.
14.14.4 Signals
Table 414: SPVNZBAT Input signals
Name Type Default Description
U_BATT REAL 0.00 Battery terminal voltage that has to be supervised
BLOCK BOOLEAN 0 Blocks all the output signals of the function
Table 415: SPVNZBAT Output signals
Name Type Description
AL_ULOW BOOLEAN Alarm when voltage has been below low limit for a
set time
AL_UHI BOOLEAN Alarm when voltage has exceeded high limit for a
set time
ST_ULOW BOOLEAN Start signal when battery voltage drops below
lower limit
ST_UHI BOOLEAN Start signal when battery voltage exceeds upper
limit
14.14.5 Settings
Table 416: SPVNZBAT Non group settings (basic)
Name
Values (Range) Unit Step Default Description
Operation Off
On
- - On Operation mode Off / On
RtdBattVolt 20.00 - 250.00 V 1.00 110.00 Battery rated voltage
BattVoltLowLim 60 - 140 %Ubat 1 70 Lower limit for the battery terminal voltage
BattVoltHiLim 60 - 140 %Ubat 1 120 Upper limit for the battery terminal voltage
tDelay 0.000 - 60.000 s 0.001 0.200 Delay time for alarm
tReset 0.000 - 60.000 s 0.001 0.000 Time delay for reset of alarm
Section 14 1MRK 502 048-UEN A
Monitoring
552
Technical manual
