Table 450: PCGGIO Output signals
Name Type Description
INVALID BOOLEAN The pulse counter value is invalid
RESTART BOOLEAN The reported value does not comprise a complete
integration cycle
BLOCKED BOOLEAN The pulse counter function is blocked
NEW_VAL BOOLEAN A new pulse counter value is generated
SCAL_VAL REAL Scaled value with time and status information
15.1.5 Settings
Table 451: PCGGIO Non group settings (basic)
Name Values (Range) Unit Step Default Description
Operation Off
On
- - Off Operation Off/On
EventMask NoEvents
ReportEvents
- - NoEvents Report mask for analog events from pulse
counter
CountCriteria Off
RisingEdge
Falling edge
OnChange
-
- RisingEdge Pulse counter criteria
Scale 1.000 - 90000.000 - 0.001 1.000 Scaling value for SCAL_VAL output to unit
per counted value
Quantity Count
ActivePower
ApparentPower
ReactivePower
ActiveEnergy
ApparentEnergy
ReactiveEnergy
-
- Count Measured quantity for SCAL_VAL output
tReporting 1 - 3600 s 1 60 Cycle time for reporting of counter value
15.1.6 Monitored data
Table 452: PCGGIO Monitored data
Name
Type Values (Range) Unit Description
CNT_VAL INTEGER - - Actual pulse counter
value
SCAL_VAL REAL - - Scaled value with time
and status information
15.1.7 Operation principle
The registration of pulses is done according to setting of CountCriteria parameter on
one of the 9 binary input channels located on the BIO module. Pulse counter values are
sent to the station HMI with predefined cyclicity without reset.
Section 15 1MRK 502 048-UEN A
Metering
588
Technical manual
