Name Type Values (Range) Unit Description
UnTrigStatCh34 BOOLEAN - - Under level trig for analog
channel 34 activated
OvTrigStatCh34 BOOLEAN - - Over level trig for analog
channel 34 activated
UnTrigStatCh35 BOOLEAN - - Under level trig for analog
channel 35 activated
OvTrigStatCh35 BOOLEAN - - Over level trig for analog
channel 35 activated
UnTrigStatCh36 BOOLEAN - - Under level trig for analog
channel 36 activated
OvTrigStatCh36 BOOLEAN - - Over level trig for analog
channel 36 activated
UnTrigStatCh37 BOOLEAN - - Under level trig for analog
channel 37 activated
OvTrigStatCh37 BOOLEAN - - Over level trig for analog
channel 37 activated
UnTrigStatCh38 BOOLEAN - - Under level trig for analog
channel 38 activated
OvTrigStatCh38 BOOLEAN - - Over level trig for analog
channel 38 activated
UnTrigStatCh39 BOOLEAN - - Under level trig for analog
channel 39 activated
OvTrigStatCh39 BOOLEAN - - Over level trig for analog
channel 39 activated
UnTrigStatCh40 BOOLEAN - - Under level trig for analog
channel 40 activated
OvTrigStatCh40 BOOLEAN - - Over level trig for analog
channel 40 activated
FaultNumber INTEGER - - Disturbance fault number
14.4.3 Analog input signals AxRADR
14.4.3.1 Identification
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Analog input signals A1RADR - -
Analog input signals A2RADR - -
Analog input signals A3RADR - -
Section 14 1MRK 502 048-UEN A
Monitoring
512
Technical manual
