Function block
SRMEMORY
SET
RESET
OUT
NOUT
IEC09000293-1-en.vsd
IEC09000293 V1 EN
Figure 226: SRMEMORY function block
Signals
Table 320: SRMEMORY Input signals
Name Type Default Description
SET BOOLEAN 0 Input signal to set
RESET BOOLEAN 0 Input signal to reset
Table 321: SRMEMORY Output signals
Name Type Description
OUT BOOLEAN Output signal
NOUT BOOLEAN Inverted output signal
Settings
Table 322: SRMEMORY Group settings (basic)
Name
Values (Range) Unit Step Default Description
Memory Off
On
- - On Operating mode of the memory function
13.3.1.11 Reset-set with memory function block RSMEMORY
Identification
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Reset-set with memory function block RSMEMORY - -
Functionality
The Reset-set with memory function block (RSMEMORY) is a flip-flop with memory
that can reset or set an output from two inputs respectively. Each RSMEMORY
function block has two outputs, where one is inverted. The memory setting controls if
the flip-flop after a power interruption will return the state it had before or if it will be
reset. For a Reset-Set flip-flop, RESET input has higher priority over SET input.
Section 13 1MRK 502 048-UEN A
Logic
450
Technical manual
