13.9.2 Functionality
Elapsed Time Integrator (TEIGGIO) function is a function that accumulates the
elapsed time when a given binary signal has been high.
The main features of TEIGGIO are
• Applicable to long time integration (≤999 999.9 seconds).
• Supervision of limit transgression conditions and overflow.
• Possibility defining a warning or alarm with the resolution of 10 milliseconds.
• Retain the integration value at a warning/alarm/overflow.
• Possibilities for blocking and reset.
• Report the integrated time
13.9.3 Function block
TEIGGIO
BLOCK
IN
RESET
WARNING
ALARM
OVERFLOW
ACCTIME
IEC13000005-1-en.vsd
IEC13000005 V1 EN
Figure 233: TEIGGIO function block
13.9.4 Signals
Table 341: TEIGGIO Input signals
Name
Type Default Description
BLOCK BOOLEAN 0 Freeze the integration and block the other outputs
IN BOOLEAN 0 The input signal that is used to measure the
elapsed time, when its value is high
RESET BOOLEAN 0 Reset the integration time
Table 342: TEIGGIO Output signals
Name
Type Description
WARNING BOOLEAN Indicator of the integrated time has reached the
warning limit
ALARM BOOLEAN Indicator of the integrated time has reached the
alarm limit
OVERFLOW BOOLEAN Indicator of the integrated time has reached the
overflow limit
ACCTIME REAL Integrated elapsed time in seconds
