17.16.2.4 Settings
The function does not have any parameters available in the local HMI or PCM600.
17.16.2.5 Monitored data
Table 527: DOSFRNT Monitored data
Name Type Values (Range) Unit Description
State INTEGER 0=Off
1=Normal
2=Throttle
3=DiscardLow
4=DiscardAll
5=StopPoll
-
Frame rate control state
Quota INTEGER - % Quota level in percent
0-100
IPPackRecNorm INTEGER - - Number of IP packets
received in normal mode
IPPackRecPoll INTEGER - - Number of IP packets
received in polled mode
IPPackDisc INTEGER - - Number of IP packets
discarded
NonIPPackRecNorm INTEGER - - Number of non IP
packets received in
normal mode
NonIPPackRecPoll
INTEGER - - Number of non IP
packets received in
polled mode
NonIPPackDisc
INTEGER - - Number of non IP
packets discarded
17.16.3 Denial of service, frame rate control for LAN1 port DOSLAN1
17.16.3.1 Identification
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Denial of service, frame rate control for
LAN1 port
DOSLAN1 - -
1MRK 502 048-UEN A Section 17
Basic IED functions
655
Technical manual
