ABB REG650 - Page 45

IEC 61850 or Function
name
ANSI Function description Generator
REG650
REG650 (B01) Gen diff REG650 (B05) Gen+Trafo diff
I103USRCMD Function commands user defined for IEC60870-5-103 4 4 4
I103GENCMD Function commands generic for IEC60870-5-103 50 50 50
I103POSCMD IED commands with position and select for
IEC60870-5-103
50 50 50
Apparatus control and Interlocking
APC8 Apparatus control for single bay, max 8 app. (1CB) incl.
interlocking
0–1
SCILO 3 Logical node for interlocking
BB_ES 3 Interlocking for busbar earthing switch
A1A2_BS 3 Interlocking for bus-section breaker
A1A2_DC 3 Interlocking for bus-section disconnector
ABC_BC 3 Interlocking for bus-coupler bay
BH_CONN 3 Interlocking for 1 1/2 breaker diameter
BH_LINE_A 3 Interlocking for 1 1/2 breaker diameter
BH_LINE_B 3 Interlocking for 1 1/2 breaker diameter
DB_BUS_A 3 Interlocking for double CB bay
DB_BUS_B 3 Interlocking for double CB bay
DB_LINE 3 Interlocking for double CB bay
ABC_LINE 3 Interlocking for line bay
AB_TRAFO 3 Interlocking for transformer bay
SCSWI Switch controller
QCBAY Bay control 1 1 1
LOCREM Handling of LR-switch positions 1 1 1
LOCREMCTRL LHMI control of Permitted Source To Operate (PSTO) 1 1 1
CBC1 Circuit breaker control for 1CB 0–1 1
CBC2 Circuit breaker control for 2CB 0–1 1
Secondary system supervision
SDDRFUF Fuse failure supervision 0–1 1 1
TCSSCBR Breaker close/trip circuit monitoring 3 3 3
Logic
SMPPTRC 94 Tripping logic, common 3–phase output 1–6 6 6
TMAGGIO Trip matrix logic 12 12 12
OR Configurable logic blocks 283 283 283
INVERTER Configurable logic blocks 140 140 140
PULSETIMER Configurable logic blocks 40 40 40
GATE Configurable logic blocks 40 40 40
Table continues on next page
1MRK 502 048-UEN A Section 2
Available functions
