ABB REG650 - Page 47

IEC 61850 or Function
name
ANSI Function description Generator
REG650
REG650 (B01) Gen diff REG650 (B05) Gen+Trafo diff
TM_P_P2 Function block for service values presentation of primary
analog inputs 600TRM
1 1 1
AM_P_P4 Function block for service values presentation of primary
analog inputs 600AIM
1 1 1
TM_S_P2 Function block for service values presentation of
secondary analog inputs 600TRM
1 1 1
AM_S_P4 Function block for service values presentation of
secondary analog inputs 600AIM
1 1 1
CNTGGIO Event counter 5 5 5
L4UFCNT Event counter with limit supervision 12 12 12
DRPRDRE Disturbance report 1 1 1
AnRADR Analog input signals 4 4 4
BnRBDR Binary input signals 6 6 6
SPGGIO IEC 61850 generic communication I/O functions 64 64 64
SP16GGIO IEC 61850 generic communication I/O functions 16
inputs
16 16 16
MVGGIO IEC 61850 generic communication I/O functions 16 16 16
MVEXP Measured value expander block 66 66 66
SPVNZBAT Station battery supervision 0–1 1 1
SSIMG 63 Insulation gas monitoring function 0–2 2 2
SSIML 71 Insulation liquid monitoring function 0–2 2 2
SSCBR Circuit breaker condition monitoring 0–1 1 1
I103MEAS Measurands for IEC60870-5-103 1 1 1
I103MEASUSR Measurands user defined signals for IEC60870-5-103 3 3 3
I103AR Function status auto-recloser for IEC60870-5-103 1 1 1
I103EF Function status earth-fault for IEC60870-5-103 1 1 1
I103FLTPROT Function status fault protection for IEC60870-5-103 1 1 1
I103IED IED status for IEC60870-5-103 1 1 1
I103SUPERV Supervison status for IEC60870-5-103 1 1 1
I103USRDEF Status for user defined signals for IEC60870-5-103 20 20 20
Metering
PCGGIO Pulse counter 16 16 16
ETPMMTR Function for energy calculation and demand handling 3 3 3
1MRK 502 048-UEN A Section 2
Available functions
41
Technical manual
