Name Values (Range) Unit Step Default Description
FunType5 0 - 255 - 1 0 Function type for analog channel 5
(IEC-60870-5-103)
InfNo5 0 - 255 - 1 0 Information number for analog channel 5
(IEC-60870-5-103)
FunType6 0 - 255 - 1 0 Function type for analog channel 6
(IEC-60870-5-103)
InfNo6 0 - 255 - 1 0 Information number for analog channel 6
(IEC-60870-5-103)
FunType7 0 - 255 - 1 0 Function type for analog channel 7
(IEC-60870-5-103)
InfNo7 0 - 255 - 1 0 Information number for analog channel 7
(IEC-60870-5-103)
FunType8 0 - 255 - 1 0 Function type for analog channel 8
(IEC-60870-5-103)
InfNo8 0 - 255 - 1 0 Information number for analog channel 8
(IEC-60870-5-103)
FunType9 0 - 255 - 1 0 Function type for analog channel 9
(IEC-60870-5-103)
InfNo9 0 - 255 - 1 0 Information number for analog channel 9
(IEC-60870-5-103)
FunType10 0 - 255 - 1 0 Function type for analog channel 10
(IEC-60870-5-103)
InfNo10 0 - 255 - 1 0 Information number for analog channel10
(IEC-60870-5-103)
Table 391: A1RADR Non group settings (advanced)
Name
Values (Range) Unit Step Default Description
NomValue01 0.0 - 999999.9 - 0.1 0.0 Nominal value for analog channel 1
UnderTrigOp01 Off
On
- - Off Use under level trigger for analog channel
1 (on) or not (off)
UnderTrigLe01 0 - 200 % 1 50 Under trigger level for analog channel 1 in
% of signal
OverTrigOp01 Off
On
- - Off Use over level trigger for analog channel 1
(on) or not (off)
OverTrigLe01 0 - 5000 % 1 200 Over trigger level for analog channel 1 in
% of signal
NomValue02 0.0 - 999999.9 - 0.1 0.0 Nominal value for analog channel 2
UnderTrigOp02 Off
On
- - Off Use under level trigger for analog channel
2 (on) or not (off)
UnderTrigLe02 0 - 200 % 1 50 Under trigger level for analog channel 2 in
% of signal
OverTrigOp02 Off
On
- - Off Use over level trigger for analog channel 2
(on) or not (off)
OverTrigLe02 0 - 5000 % 1 200 Over trigger level for analog channel 2 in
% of signal
NomValue03 0.0 - 999999.9 - 0.1 0.0 Nominal value for analog channel 3
Table continues on next page
