Name Values (Range) Unit Step Default Description
InfNo31 0 - 255 - 1 0 Information number for analog channel 31
(IEC-60870-5-103)
FunType32 0 - 255 - 1 0 Function type for analog channel 32
(IEC-60870-5-103)
InfNo32 0 - 255 - 1 0 Information number for analog channel 32
(IEC-60870-5-103)
FunType33 0 - 255 - 1 0 Function type for analog channel 33
(IEC-60870-5-103)
InfNo33 0 - 255 - 1 0 Information number for analog channel 33
(IEC-60870-5-103)
FunType34 0 - 255 - 1 0 Function type for analog channel 34
(IEC-60870-5-103)
InfNo34 0 - 255 - 1 0 Information number for analog channel 34
(IEC-60870-5-103)
FunType35 0 - 255 - 1 0 Function type for analog channel 35
(IEC-60870-5-103)
InfNo35 0 - 255 - 1 0 Information number for analog channel 35
(IEC-60870-5-103)
FunType36 0 - 255 - 1 0 Function type for analog channel 36
(IEC-60870-5-103)
InfNo36 0 - 255 - 1 0 Information number for analog channel 36
(IEC-60870-5-103)
FunType37 0 - 255 - 1 0 Function type for analog channel 37
(IEC-60870-5-103)
InfNo37 0 - 255 - 1 0 Information number for analog channel 37
(IEC-60870-5-103)
FunType38 0 - 255 - 1 0 Function type for analog channel 38
(IEC-60870-5-103)
InfNo38 0 - 255 - 1 0 Information number for analog channel 38
(IEC-60870-5-103)
FunType39 0 - 255 - 1 0 Function type for analog channel 39
(IEC-60870-5-103)
InfNo39 0 - 255 - 1 0 Information number for analog channel 39
(IEC-60870-5-103)
FunType40 0 - 255 - 1 0 Function type for analog channel 40
(IEC-60870-5-103)
InfNo40 0 - 255 - 1 0 Information number for analog channel40
(IEC-60870-5-103)
Table 394: A4RADR Non group settings (advanced)
Name
Values (Range) Unit Step Default Description
NomValue31 0.0 - 999999.9 - 0.1 0.0 Nominal value for analog channel 31
UnderTrigOp31 Off
On
- - Off Use under level trigger for analog channel
31 (on) or not (off)
UnderTrigLe31 0 - 200 % 1 50 Under trigger level for analog channel 31
in % of signal
Table continues on next page
