ABB REG650 - Page 669

Terminal Description PCM600 info
Hardware module
instance
Hardware channel
X329-6 Binary input 3 + BIO_4 BI3
X329-7 -
X329-8 Common - for inputs 4-5
X329-9 Binary input 4 + BIO_4 BI4
X329-10 Binary input 5 + BIO_4 BI5
X329-11 -
X329-12 Common - for inputs 6-7
X329-13 Binary input 6 + BIO_4 BI6
X329-14 Binary input 7 + BIO_4 BI7
X329-15 -
X329-16 Common - for inputs 8-9
X329-17 Binary input 8 + BIO_4 BI8
X329-18 Binary input 9 + BIO_4 BI9
Table 538: Binary inputs X334, 3U full 19”
Terminal
Description
PCM600 info
Hardware module
instance
Hardware channel
X334-1 - for input 1 BIO_5 BI1
X334-2 Binary input 1 + BIO_5 BI1
X334-3 -
X334-4 Common - for inputs 2-3
X334-5 Binary input 2 + BIO_5 BI2
X334-6 Binary input 3 + BIO_5 BI3
X334-7 -
X334-8 Common - for inputs 4-5
X334-9 Binary input 4 + BIO_5 BI4
X334-10 Binary input 5 + BIO_5 BI5
X334-11 -
X334-12 Common - for inputs 6-7
X334-13 Binary input 6 + BIO_5 BI6
X334-14 Binary input 7 + BIO_5 BI7
X334-15 -
X334-16 Common - for inputs 8-9
X334-17 Binary input 8 + BIO_5 BI8
X334-18 Binary input 9 + BIO_5 BI9
1MRK 502 048-UEN A Section 18
IED physical connections
663
Technical manual
