ABB REL650 - Page 39

IEC 61850 or Function
name
ANSI Function description Line Distance
REL650
REL650 (A01A)
3Ph/1CB
REL650 (A11A)
1Ph/1CB
REL650 (B01A)
3P h/2CB
DB_LINE 3 Interlocking for double CB bay
ABC_LINE 3 Interlocking for line bay
AB_TRAFO 3 Interlocking for transformer bay
SCSWI Switch controller
QCBAY Bay control 1 1 1 1
LOCREM Handling of LR-switch positions 1 1 1 1
LOCREMCTRL LHMI control of Permitted Source To Operate
(PSTO)
1 1 1 1
CBC1 Circuit breaker control for 1CB 0–1 1 1
CBC2 Circuit breaker control for 2CB 0–1 1
Secondary system supervision
CCSRDIF 87 Current circuit supervision 0–2 1 1 2
SDDRFUF Fuse failure supervision 0–3 1 1 3
TCSSCBR Breaker close/trip circuit monitoring 3 3 3 3
Logic
SMPPTRC 94 Tripping logic, common 3–phase output 1–2 1 2
SPTPTRC 94 Tripping logic, phase segregated output 1 1
TMAGGIO Trip matrix logic 12 12 12 12
OR Configurable logic blocks 283 283 283 283
INVERTER Configurable logic blocks 140 140 140 140
PULSETIMER Configurable logic blocks 40 40 40 40
GATE Configurable logic blocks 40 40 40 40
XOR Configurable logic blocks 40 40 40 40
LOOPDELAY Configurable logic blocks 40 40 40 40
TIMERSET Configurable logic blocks 40 40 40 40
AND Configurable logic blocks 280 280 280 280
SRMEMORY Configurable logic blocks 40 40 40 40
RSMEMORY Configurable logic blocks 40 40 40 40
Q/T Configurable logic blocks Q/T 0–1
ANDQT Configurable logic blocks Q/T 0–120
ORQT Configurable logic blocks Q/T 0–120
INVERTERQT Configurable logic blocks Q/T 0–120
Table continues on next page
