TMAGGIO 3 output signals and the physical outputs allows the user to adapt the signals
to the physical tripping outputs according to the specific application needs for settable
pulse or steady output.
13.3.3 Setting guidelines
Operation: Turns the operation of the function Enabled/Disabled.
PulseTime: Defines the pulse time duration. When used for direct tripping of circuit
breaker(s) the pulse time duration shall be set to approximately 0.150 seconds in order to
obtain satisfactory minimum duration of the trip pulse to the circuit breaker trip coils.
Used only for ModeOutputx: Pulsed.
OnDelay: Used to prevent output signals to be given for spurious inputs. Normally set to
0 or a low value. Used only for ModeOutputx: Steady.
OffDelay: Defines a minimum on time for the outputs. When used for direct tripping of
circuit breaker(s) the off delay time shall be set to approximately 0.150 seconds in order
to obtain a satisfactory minimum duration of the trip pulse to the circuit breaker trip coils.
Used only for ModeOutputx: Steady.
ModeOutputx: Defines if output signal OUTPUTx (where x=1-3) is Steady or Pulsed. A
steady signal follows the status of the input signals, with respect to OnDelay and
OffDelay. A pulsed signal will give a pulse once, when the Outputx rises from 0 to 1.
13.4 Configurable logic blocks
13.4.1 Identification
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
OR Function block OR - -
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Inverter function block INVERTER - -
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
PULSETIMER function block PULSETIMER - -
