14.9.3.1 Connection of analog currents
Connection diagram for analog currents is shown in figure 212.
ANSI11000062-1-en.vsd
A
B
C
IA
IB
IC
IA
IB
IC
IN IN
ANSI11000062 V1 EN
Figure 212: Example of connection of parallel line IN for Fault locator LMBRFLO
14.10 Station battery supervision SPVNZBAT
14.10.1 Identification
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Station battery supervision function SPVNZBAT U<> -
