ABB REL650 - Station Communication

2.2.4 Station communication
IEC 61850 or Function
name
ANSI Function description Line Distance
REL650
REL650 (A01A)
3Ph/1CB
REL650 (A11A)
1Ph/1CB
REL650 (B01A)
3Ph/2CB
Station communication
IEC61850-8-1 IEC 61850 communication protocol 1 1 1 1
DNPGEN DNP3.0 communication general protocol 1 1 1 1
RS485DNP DNP3.0 for RS-485 communication protocol 1 1 1 1
CH1TCP DNP3.0 for TCP/IP communication protocol 1 1 1 1
CH2TCP DNP3.0 for TCP/IP communication protocol 1 1 1 1
CH3TCP DNP3.0 for TCP/IP communication protocol 1 1 1 1
CH4TCP DNP3.0 for TCP/IP communication protocol 1 1 1 1
OPTICALDNP DNP3.0 for optical RS-232 communication
protocol
1 1 1 1
MSTSERIAL DNP3.0 for serial communication protocol 1 1 1 1
MST1TCP DNP3.0 for TCP/IP communication protocol 1 1 1 1
MST2TCP DNP3.0 for TCP/IP communication protocol 1 1 1 1
MST3TCP DNP3.0 for TCP/IP communication protocol 1 1 1 1
MST4TCP DNP3.0 for TCP/IP communication protocol 1 1 1 1
RS485GEN RS485 1 1 1 1
OPTICALPROT Operation selection for optical serial 1 1 1 1
RS485PROT Operation selection for RS485 1 1 1 1
DNPFREC DNP3.0 fault records for TCP/IP
communication protocol
1 1 1 1
OPTICAL103 IEC60870-5-103 Optical serial communication 1 1 1 1
RS485103 IEC60870-5-103 serial communication for
RS485
1 1 1 1
GOOSEINTLKRCV Horizontal communication via GOOSE for
interlocking
59 59 59 59
GOOSEBINRCV GOOSE binary receive 4 4 4 4
ETHFRNT
ETHLAN1
GATEWAY
Ethernet configuration of front port, LAN1 port
and gateway
1 1 1 1
ETHLAN1_AB Ethernet configuration of LAN1 port 1
PRPSTATUS System component for parallell redundancy
protocol
1
CONFPROT IED Configuration Protocol 1 1 1 1
Table continues on next page
Section 2 1MRK 506 334-UUS A
Application
36
Application manual
