IEC 61850 or Function
name
ANSI Function description Line Distance
REL650
REL650 (A01A)
3Ph/1CB
REL650 (A11A)
1Ph/1CB
REL650 (B01A)
3P h/2CB
L4UFCNT Event counter with limit supervision 12 12 12 12
DRPRDRE Disturbance report 1 1 1 1
AnRADR Analog input signals 4 4 4 4
BnRBDR Binary input signals 6 6 6 6
SPGGIO IEC 61850 generic communication I/O functions 64 64 64 64
SP16GGIO IEC 61850 generic communication I/O functions
16 inputs
16 16 16 16
MVGGIO IEC 61850 generic communication I/O functions 16 16 16 16
MVEXP Measured value expander block 66 66 66 66
LMBRFLO Fault locator 1 1 1 1
SPVNZBAT Station battery supervision 0–1 1 1 1
SSIMG 63 Insulation gas monitoring function 0–2 1 1 2
SSIML 71 Insulation liquid monitoring function 0–2 1 1 2
SSCBR Circuit breaker condition monitoring 0–2 1 1 2
I103MEAS Measurands for IEC60870-5-103 1 1 1 1
I103MEASUSR Measurands user defined signals for
IEC60870-5-103
3 3 3 3
I103AR Function status auto-recloser for IEC60870-5-103 1 1 1 1
I103EF Function status ground-fault for IEC60870-5-103 1 1 1 1
I103FLTPROT Function status fault protection for
IEC60870-5-103
1 1 1 1
I103IED IED status for IEC60870-5-103 1 1 1 1
I103SUPERV Supervison status for IEC60870-5-103 1 1 1 1
I103USRDEF Status for user defined signals for IEC60870-5-103 20 20 20 20
Metering
PCGGIO Pulse counter 16 16 16 16
ETPMMTR Function for energy calculation and demand
handling
3 3 3 3
1MRK 506 334-UUS A Section 2
Application
35
Application manual
