2.2.3 Control and monitoring functions
IEC 61850 or Function
name
ANSI Function description Line Distance
REL650
REL650 (A01A)
3Ph/1CB
REL650 (A11A)
1Ph/1CB
REL650 (B01A)
3P h/2CB
Control
SESRSYN 25 Synchrocheck, energizing check, and
synchronizing
0–2 1 1 2
SMBRREC 79 Autorecloser for 3–phase operation 0–2 1 2
STBRREC 79 Autorecloser for 1/3–phase operation 0–1 1
SLGGIO Logic Rotating Switch for function selection and
LHMI presentation
15 15 15 15
VSGGIO Selector mini switch 20 20 20 20
DPGGIO IEC 61850 generic communication I/O functions
double point
16 16 16 16
SPC8GGIO Single point generic control 8 signals 5 5 5 5
AUTOBITS AutomationBits, command function for DNP3.0 3 3 3 3
I103CMD Function commands for IEC60870-5-103 1 1 1 1
I103IEDCMD IED commands for IEC60870-5-103 1 1 1 1
I103USRCMD Function commands user defined for
IEC60870-5-103
4 4 4 4
I103GENCMD Function commands generic for IEC60870-5-103 50 50 50 50
I103POSCMD IED commands with position and select for
IEC60870-5-103
50 50 50 50
Apparatus control and Interlocking
APC8 Apparatus control for single bay, max 8 app. (1CB)
incl. interlocking
0–1
SCILO 3 Logical node for interlocking
BB_ES 3 Interlocking for busbar earthing switch
A1A2_BS 3 Interlocking for bus-section breaker
A1A2_DC 3 Interlocking for bus-section disconnector
ABC_BC 3 Interlocking for bus-coupler bay
BH_CONN 3 Interlocking for 1 1/2 breaker diameter
BH_LINE_A 3 Interlocking for 1 1/2 breaker diameter
BH_LINE_B 3 Interlocking for 1 1/2 breaker diameter
DB_BUS_A 3 Interlocking for double CB bay
DB_BUS_B 3 Interlocking for double CB bay
Table continues on next page
Section 2 1MRK 506 334-UUS A
Application
32
Application manual
