ABB REL650 - Basic IED Functions

IEC 61850 or Function
name
ANSI Function description Line Distance
REL650
REL650 (A01A)
3Ph/1CB
REL650 (A11A)
1Ph/1CB
REL650 (B01A)
3Ph/2CB
ACTIVLOG Activity logging parameters 1 1 1 1
SECALARM Component for mapping security events on
protocols such as DNP3 and IEC103
1 1 1 1
AGSAL Generic security application component 1 1 1 1
GOOSEDPRCV GOOSE function block to receive a double point
value
32 32 32 32
GOOSEINTRCV GOOSE function block to receive an integer
value
32 32 32 32
GOOSEMVRCV GOOSE function block to receive a measurand
value
16 16 16 16
GOOSESPRCV GOOSE function block to receive a single point
value
64 64 64 64
Scheme communication
ZCPSCH 85 Scheme communication logic with delta based
blocking scheme signal transmit
0–1 1 1 1
ZCRWPSCH 85 Current reversal and WEI logic for distance
protection, 3–phase
0–1 1 1
ZCWSPSCH 85 Current reversal and WEI logic for distance
protection, phase segregated
0–1 1
ZCLCPLAL Local acceleration logic 1 1 1 1
ECPSCH 85 Scheme communication logic for residual
overcurrent protection
0–1 1 1 1
ECRWPSCH 85 Current reversal and weak-end infeed logic for
residual overcurrent protection
0–1 1 1 1
2.2.5 Basic IED functions
IEC 61850/Function
block name
Function description
Basic functions included in all products
INTERRSIG Self supervision with internal event list 1
SELFSUPEVLST Self supervision with internal event list 1
TIMESYNCHGEN Time synchronization 1
SNTP Time synchronization 1
DTSBEGIN, DTSEND,
TIMEZONE
Time synchronization, daylight saving 1
Table continues on next page
1MRK 506 334-UUS A Section 2
Application
37
Application manual
