4 RUNNING A TEST
How to insert an m-PIMA™ Test Cartridge
To insert a test cartridge you rst need to manually slide the m-PIMA™
Analyser door to the le to get full access to the cartridge slot. Since the door
will automacally close you need to hold it open while inserng the cartridge.
• Insert the cartridge in the direcon indicated by an arrow on the cartridge
label.
• Insert the cartridge in a slightly downward angle and push it beyond the
catch unl it is locked in place.
• Release the door which will then close by itself.
Upon inserng a m-PIMA™ test cartridge the internal sensors will detect its
presence and iniate the test analysis sequence.
