Abicor Binzel TCS-Compact - Page 35

TCS-Compact 2 Product description
EN - 5
1 Cleaning unit
2 Collecting tray
3 Bottle holder for anti-spatter bottle 4 Support stand with flange plate
Fig. 2 Technical Data - Version with short support
1
2
3
4
2
136
370
260
57
230
200
11 0
ø 11 (4x)
337
107
190
60
477
Ambient temperature + 5 °C to + 50 °C
Transport and storage - 10 °C to + 55 °C
Relative humidity up to 90 % at 20 °C
Tab. 2 Ambient conditions
Version with long support Version with short support
Weight approx. 30 kg approx. 22,3 kg
Dimension approx. 255 mm x 337 mm x 1052 mm approx. 255 mm x 337 mm x 477 mm
Tab. 3 Weight, dimensions
