TCS-Compact 6 Putting into operation
EN - 21
6.2.5 Setting up the clamping position
Fig. 16 Position bellows
NOTE
• Only use clamping prisms and milling cutters adjusted to the gas nozzle diameter.
 See Fig. 17 Setting up the clamping position on page EN-21
1 Clamping prism
2 Gas nozzle
3 Cleaning station
4 Gas nozzle clamping device
5 Clamping position
Fig. 17 Setting up the clamping position
Tool axis
12
3
4
5
