Abicor Binzel TCS-Compact - Connecting the Pneumatic System

TCS-Compact 6 Putting into operation
EN - 27
6.6 Connecting the pneumatic system
For the supply, a compressed air-hose with a min. inner width of ø 6mm is required; it is fastened to the
housing by means of a screw connection (not included in the delivery). A compressed air shut-off valve in
the supply line is recommended. This allows the TCS-Compact to be quickly and simply depressurized in
order to carry out any installation and maintenance work.
Fig. 22 Connecting the pneumatic system
minimum 6bar
Z1
Z2
S1
S2
Y1
Y2
Y3
Y4
Cleaning stroke cylinder
up
close
up
down
Clamping / cutter
Vacuum output
Compressed air
Suction
(Air motor)
Return
Anti-spatter
Air motor
1
1
1
1
2
2
2
2
3
3
3
3
4
4
4
5
5
5
10
12
45°
12
12
1214
14
14
14
14
14
14
12
M
1
