EN - 6
2 Product description TCS-Compact
2.4 Abbreviations
Compressed air connection G1/4"
Inner width min.
ø 6 mm
Nominal pressure 6 bar
Working pressure 6 - 8 bar
Quality of compressed air (ISO 8573-1:2010) min. class 4
Tab. 4 Pneumatic distributor block
Operating voltage/Internal operating voltage 24 VDC / 200 mA
Protection type IP 21
3 inputs of the 5/2 directional valves
Activation 24 VDC
Power consumption per valve 2,8 W
2 outputs of inductive proximity switch (normally open switch) (pnp ≠ Plus switching/
npn ≠ Minus switching)
1
1see nameplate
Operating voltage 10 - 30 V DC
Current consumption approx. 4 mA (24 V)
Allowed residual ripple Vss < 10 %
Permanent current per proximity switch max. 100 mA
Voltage drop approx. 1.5 V (200 mA)
Tab. 5 Electrical clamping block
Pneumatic motor / nominal speed with oiled air approx. 650 rpm at 6 bar
Air consumption approx. 400 l/min
Repository volume (anti-spatter fluid) 1 l
Air supply connection Inner width 6 mm
max. torque 8 Nm
Tab. 6 Compressed air-motor TCS-Compact
Injection unit 1 litre bottle capacity
Operating pressure max. 6 bar
max. actuation time 4 s
Consumption anti-spatter depending on the dosage setting
Tab. 7 Injection unit
Cutting capacity at 6 bar
Solid wire up to 1.6 mm
Cutting time 1,0 seconds
Tab. 8 Wire cutting device
TCS-Compact Cleaning station
DAV Wire cutting device
TCP Tool Center Point
Tab. 9 Abbreviations
