TCS-Compact 5 Functional description
EN - 11
5.2 Wire cutting device sub-assembly
5.3 Sub-assemblies accessories / options
1 Wire cutting device
2 Protection plate
3 Movable cutting plate 4 Fixed cutting plate
Fig. 6 DAV wire cutting device sub-assembly
Wire cutter closed
Wire cutter open
1
2
3
4
Prism Anti-twist fastening with a cylinder head screw M8x20 in the clamping device (depending on the
diameter of the gas nozzle).
Milling cutter The milling cutter dimensions are determined based on the gas nozzle and torch geometry for an
immersion depth up to 50 mm. Available for all standard WH and robot torch versions.
Tab. 12 Accessories
Maintenance unit ID 830.0075
Consists of a filter regulator and oiler.
The maintenance unit separates solid particles from the compressed air and adds atomized oil for
lubricating the pneumatically driven components.
Tab. 13 Options
