6 Putting into operation TCS-Compact
Y2 5/2 directional valve for clamping cylinder (CLAMP - RELEASE)
Y2 5/2 directional valve for wire cutter (ON - OFF)
Y3 5/2 directional valve for injector (ON - OFF)
Air-blast option Air-blast through cable assembly (ON - OFF)
Ready Home position of the cleaning station (stroke cylinder down, S1 activated)
S1 Lift down
S2 Clamping cylinder open
NOTE
• If the operating pressure is too low (<5 bar), the waiting time for injection may increase.
Tab. 14 Explanations
