72
This parameter is used to reset the programmable parameters back to the factory
default settings. This parameter has four possible settings:
MAINTAIN Maintain parameter settings as they are.
RESET 60 Resets parameters to factory defaults for 60 Hz base frequency.
RESET 50 Resets parameters to factory defaults for 50 Hz base frequency.
RST HIGH Resets parameters to factory defaults for 650 Hz base
frequency. This option will only appear if the drive is
equipped with the High Frequency Output option.
When a factory reset is performed, the following terminals are affected:
TB-1 will be disabled as a STOP input because Parameter 30 - CONTROL will
default to LOCAL.
TB-13A, 13B, and 13C will be disabled because Parameters 47, 48, and 49 will
default to NONE. If TB-13C was set to RUN REVERSE, TB-12A will default to
a momentary START contact.
TB-13D will default to a normally open EXTERNAL FAULT contact because
Parameter 50 - TB13D will be reset to EXT FAULT.
NOTE: This parameter will display RESET 60, RESET 50 or RST HIGH until
a change is made to one or more of the parameter settings. Once a parameter is
changed, the display will change to MAINTAIN.
66 HISTORY (CLEAR FAULT HISTORY)
This parameter is used to clear the previous faults in the FAULT HISTORY.
When set to CLEAR and the ENTER key is pushed, the display will change to
MAINTAIN, and the FAULT HISTORY will display NO FAULT for each of the
eight fault histories.
69 LANGUAGE (LANGUAGE SELECTION)
The MC Series drive can support other languages with the addition of an optional
LANGUAGE EEPROM chip installed in socket U11 on the control board of the
drive. If the EEPROM is not present, the default language will be ENGLISH.
Also, this parameter is not affected when the parameters are reset using Parameter
65 - PROGRAM. Therefore, if a language other than ENGLISH is selected, it will
remain in effect after a RESET.
