RTCA SP Instrument Operator’s Manual
A
A
2.4 Specifi cations of the E-Plate 96
Footprint: complying with ANSI/SBS 1-2004 requirements
Dimension: 12.77 cm × 8.55 cm × 1.75 cm (W × D × H) (with plate cover)
Spacing: The spacing of the wells is 9 mm center-to-center as per the ANSI/SBS
4-2004 standard for 96-well titer plates
Volume: 243 µl ± 5 µl
Bottom Diameter: 5.0 mm ± 0.05 mm
Electrical Interface: Interface with RTCA SP Station
Sensor Impedance: 17 Ω ± 5 Ω at 10 kHz, when measured with a 1X PBS Solution
Material: Biocompatible surfaces
UV irradiated
Environment: temperature, +15°C to +40°C; relative humidity, 98% maximum without
condensation
2.5 Specifi cations of the RTCA Resistor Plate 96
Dimension: 12.77 cm × 8.55 cm × 1.75 cm (W × D × H) (with plate cover)
Electrical Interface: Interface with RTCA SP Station
Environment: temperature, +15°C to +40°C; relative humidity, 98% maximum without
condensation
Resistor values: 37.4, 64.9, 91.0, 115.0 Ω, ± 0.5%
e resistor values speci ed for the RTCA Resistor Plate 96 are di erent variables
than raw scan data acquired during resistor plate veri cation. erefore, they are not
comparable to acceptance values listed in chapter Resistor Plate Veri cation of the
RTCA SP Instrument.
