RTCA SP Instrument Operator’s Manual

2.3 RTCA Control Unit

 e RTCA Control Unit consists of a laptop computer (Figure 9).  e operating system

and all so ware tools necessary to run the RTCA SP Instrument are already pre-installed.

Figure 9: The RTCA Control Unit.

RTCA Control Unit Cat. No. 05454417001

System Description

RTCA Control Unit
