51
Maintenance and Care
D
D
Remove the old fuses from the drawer.
Insert new fuses as shown.
Figure 35: Inserting new fuses in the drawer.
Press the fuse drawer, along with the fuses, into the AC Receptacle. Ensure that both
ends of the drawer snap completely into place.
Figure 36: Inserting the fuse drawer.
Exchanging Fuses
Remove the old fuses from the drawer.
Insert new fuses as shown.
Figure 35: Inserting new fuses in the drawer.
Press the fuse drawer, along with the fuses, into the AC Receptacle. Ensure that both
ends of the drawer snap completely into place.
Figure 36: Inserting the fuse drawer.
Figure 36: Inserting the fuse drawer.
