Hardware Specifications and Configurations 1-15
Figure 1-4. Left View
Table 1-4. Left View
# Icon Item Description
1 DC-in jack Connects to an AC adapter.
2 Ethernet (RJ-45) port Connects to an Ethernet 10/100 based
network.
3 External display
(VGA) port
Connects to a display device (e.g., external
monitor, LCD projector).
4 USB 2.0 port Connects to USB 2.0 devices (e.g., USB mouse,
USB camera).
